8 PORT MANAGED FAST ETHERNET SWITCH (Model: TSW 1008)

8 PORT MANAGED FAST ETHERNET SWITCH


Telenet's managed switch is the latest generation of fast Ethernet switching technology. Enhanced by its many, features including port Trucking, VLAN tagging, spanning tree, and broadcast storm filters. Eight 10/100Base-TX auto sensing, auto MDI/MDIX ports provide a completely flexible high-performance non-blocking full wire speed. Solution. The management features include port-based, dynamic and static VLAN, s, GVRP, VLAN tagging, IGMP snooping, port mirroring and port security. Two priority queues per port insure minimum delay for voice over IP or multimedia broadcasting

Network management can be accessed via Telenet from anywhere on the network or via a console port at the switch. Power: 110/220V AC. The 10/100Mbps ports supporting auto-sensing and auto-negotiation of network speeds and full/half duplex. These ports can connect to workstations and print servers, giving each a dedicated bandwidth. All ports support auto MDI-II/MDI-X uplink, allowing you to connect to workstations, servers, or other switches from any port without the need to change your usual straight-through to twisted-pair cables. Flow Control to Prevent Packet loss The switch supports standard IEEE 802.3x Flow Control. Working in conjunction with buffer overrun auto detection. This full-duplex data transfer mode provides protection against possible data loss for 802.3x supported servers directly connected to the switch. The advanced features, 802.1p, Diffuser, 802.1x*, IGMP, and 802.1q, facilitate the deployment of applications across an enterprise such as: VOIP, streaming media, and multicast content delivery (IP video conferencing, software deployment).


TECHNICAL SPECIFICATIONS

  • Physical interface - 10/100 base T (IEEE 802.3) RJ45


SWITCH FEATURE

  • MAC table size -1024 entries in the MAC table
  • Forwarding mechanism – store and forward
  • Switch fabric -3.2gbps, supporting wire forwarding when all the ports are running at full speed.
  • VLAN groups – up to 64 different VLAN IDs simultaneously can be processed.
  • Support port mirroring / port security
  • Auto MDI-MDIX
  • Light console management
